Brand Name : TENVEO
Origin : CN(Origin)
Type : Video Conference System
Simultaneous Interpretation : No
Model Number : TEVO-NV10A
Image Sensor : 1/2.9'' type Exmor CMOS
Lens : F=5.5mm(wide)-50(tele)
Zoom : 10x zoom
Effective pixel : 2.1 mega pixel(16:9)
Horizontal Angle : Near-end 51.8°-Far-end 5.86°
Pan Tilt movement speed : Pan: 350°(max speed 80°/S), Tilt: -35°-90°(max speed 60°/S)
Minimum illumination : 0.25Lx(on)
Dimension(LXWXH) : 162*172*175 mm /257*220*210mm (before / after packing)
Weight : 1.5kg/2.85kg(before / after packing)
Color : Black
Style : SDI Camera

Keybpoard Controller Add USB PTZ Video Conference Camera 10X Zoom 2MP 3G-SDI and HDMI Outputs for Online meeting Live broadcast

1. 3G-SDI, HDMI and USB 3 outputs Simultaneously
2. HD1080P 2.1mega pixel
3. 10X optical zoom
4. Pan: 350° Tilt: 90°
5. VISCA, PELCO-D/P, RS232, RS485

  Tips1. : Press the Number(1-9) directly to call the reserved preset. Fast and Smooth

PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.

Tip2: SDI support 328ft(100m) HD-SDI video transfer, HDMI support 98ft(30m) HD video transfer and USB support 66ft(20m) HD video transfer.

Tip 3: Image Flip and Image Mirror. Press MENU - IMAGE - Mirror, and adjust Left/Right/UP/DOWN to manipulate image flip and Mirror.

• 1. RS485 control bus, can control 255pcs head-end equipment address and connect 128pcs equipment in parallel at the most, as well as 7pcs series-connected SONY video conference camera

  2. Can set and call 1-46 preset position of SONY video conference camera

  3. All input and output communication port use anti-radar design,powerful anti-jamming performance, the standard transmitting distance is 1200 meters

  4. Maximum sub-control keyboard:16

  5. Good communication compatibility, built-in many kinds of protocols·

  6. Keyboard operation password on/off/lock function

  7. Key-press warning on/off function

  8. Speed dome camera infinitely variable speed control

  9. LCD display

Highlight

• 10x optical zoom

• Sleek and intelligent design

• Crystal clear HD1080P image quality

• Accurate, smooth and silent PTZ Movement

• 3G-SDI, HDMI and USB Video OutputSimultaneously

• Preset: 9 via IR remote setting (255 via RS232)

• Wide field of view with no video distortion

• 1/2.9 inch high quality, 2.1MP (16:9) CMOS sensor

• Superior quality with Full Glass Lens Material

• Support ceiling mount, wall mount and tripod mount (Reverse mountable)

• 2D and 3D NR for best video quality in different lighting conditions

• Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control

• Compatible with most leading video conferencing software and platform



• Specially design for SONY video conference camera, completely compatible with VISCA protocol

• Can set the address code of SONY video conference camera independently

• Refurbish the program on line, compile corresponding promotion program according to the protocol and command provided by customer, customer connect keyboard controller through RS485 interface on the computer to update firmware

• Unique control code learning function, customer can revise the control code command voluntarily

• Multifold communication mode: RS485.RS422.RS232.10M internet (select to order), USB(select to order)

• All parameters are set by key-press operation procedure, it is convenient and fast

• Control the rotation of speed dome camera and swinging angle of joystick with nonpolar variable speed control to embody speed dome camera's rotating speed real-time.

Tips: How to use the Keyboard Controller to control upto 255pcs 20x Zoom PTZ Cameras, such as 20X Zoom TEVO-VHD203U or TEVO-VHD20N.

Step1.Use remote controller to set the address code of each camera separately: MENU-SYS SET-ADDRESS, Camera1:001, Camera2:002,* * *, CameraX:X.
Step2.Connect the control keyboard-camera 1-camera 2.... -cameraX in turn by using the network cable or RS485 signal line. RS-485 interface.
Step3.Setting the address code of each camera using the control keyboard:Setup-PASSWORD(8888)-CAM SET- Camera1:001, P(Protocol):PelcoD - enter - success. Setting the address codes of all other cameras by analogy,and set up the same communication protocol.
Step4.Controlling cameras by keyboard: Press the Addr button, then press 1 to control the camera1. Control the other cameras by analogy.

Pictures

Specification

Model No.	TEVO-NV10A
Image Sensor	1/2.9 inch Exmor CMOS
Effective pixel	2.1 mega pixel(16:9)
Horizontal Resolution	1080P60/50/30/25.1080i60/50,720P60/50
Focal length	F=5.5mm(wide)-50(tele)
Signal standard	NTSC/PAL
Zoom	10x zoom
Horizontal view angle	Near-end 51.8°～Far-end 5.86°
Gain control	Auto/manual
Focus	Auto/manual
SN ratio	≥50dB
Shutter speed	1/1 sec to 1/10000s (22 steps)
Preset position	Remote-controller support 9 presets PELCO Control Protocol supports 255 presets
Pan/Tilt movement range	Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S)
Control terminal	RS-232, RS485
Control Protocol	VISCA, PELCO-D, PELCO-P (RS-232, RS485)
Video output	USB, 3G-SDI, HDMI
Noise Reduction	2D/3D
Work Temperature	-10°～50°
Work Humidity	-20°～60°
Baud rate	38400/9600bps
Decoder	Built-in
Address Se	1~64
Installation	Support desktop, Tripod, Wall mount and Ceiling mount
Power supply	DC12V/2A
Power	12W
Weight	1.5kg/2.85kg(before / after packing)
Size	162*172*175mm /257*220*210mm (before / after packing)
Accessories	DC 12V Power adaptor, IR remote control, Ceiling brackets & screws, Manual, USB Ccable

Model	TENVEO-KZ1
Protocol	Pelco-D, Pelco-P, VISCA
Baud rate(bps）	1200bps, 2400bps, 4800bps, 9600bps, 19200bps
Control Address	Control 255pcs PTZ at the most, address code:0-254
Communication Mode	RS485 half-duplex, RS422 full-duplex, RS232 serial port
	RS232 serial port
Communication Range	RS485, RS422: 1200m, RS232: 10m
Cascade connection number	16 sub-control at most, controller ID:0-15
Joystick	3D（control: up, down, left, right, zoom）
Interface Mode	10PIN pressing line port, DB9 connector
Display	blue LCD
Warning Tone	Key-touch beep on/off
Power Supply	DC12V±10%
Power Consumption	6W MAX.
Working Temperature	0℃--50℃
Store Temperature	-20℃--70℃
Dimension (mm)	320×179.3×109.9
Weight （Kg）	2.8
Standard Package	5pcs/ctn
Package Weight	22kg/ctn

What's in the box     1 x Camera 1 x DC 12V power adaptor 1 x IR remote control 1 x USB Cable 1 x Celling Brackets 1 x Manual

1 X Keyboard Controller

1 x RS232 Cable

1 x power adaptor

Tenveo Camera FAQ

Q:What kind of camera should I use?

A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software.For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces.You can check our service guide for more information on different meeting room systems.



Q:Is it easy to operation?

A:Yes, it is easy to install, plug and play.



Q:Can I bring more than one person into a call at the same time?

A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops ,pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.



Q:What is the resolution of your cameras?

A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.



Q:What is the Video Connector?

A:There are USB 2.0, USB3.0,HDMI,HD-SDI,DVI,YPBPR and CVBS Video output.



Q:How many time zoom?

A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.



Q:How to control this Camera?

A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.



Q:Which kind of software compatible with this Camera?

A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh,WebEx, easy meeting, Vidtel and working with Microsoft Lync Software,and ZOOM.US, SKYPE, VIDYO Etc.
