Yongnuo YN24EX

*Supports ETTL Flash
Supports FEC, FEB, Front and Rear-curtain sync, FE lock, Modeling Light, for Canon camera menu accessible.
Supports flash ratio adjustment,there are 8 levels（1/128-1/1） for the intensity adjustment for the flash control,total 22 levels fine tuning; the tube A and tube B can flash individually,the flash index is wider and the more practical.
*The Flash tube installation
Install the tube on the top of the flash
Install the adapter ring on the front of the lens,then install the flash tube on the adapter ring.
*The flash coverage
vertical angle:Upwards,downwards 90 degrees
horizontal angle:inwards 60 degrees,outwards 30 degrees
The rotate degree of the adapter ring: upwards 50 degrees, downwards 30 degrees
The flash tube can be installed on the tripod for use.
*Ultra-fast Charging Recycle System
It just take 3 seconds at full output. Even if not using the brand new batteries, it just takes 4~5 seconds to recycle;
*C.Fn Setting Custom Function
You can customize the function as needed through the custom function.
*LED focus assist light
The LED focus assist light is divided into low light and highlight mode,achieve rapid precise focus.
*Equipped with PC sync interface
The YN24EX is equipped with standard PC synchronous interface which allows you convenient to use synchronous flash by using PC synchronous line.
*Supports the lens of multiple filter size
Supports the lens of the following filter size : 52mm.58mm.67mm.72mm.
*Low battery remind function
When the battery power is insufficient,the red light will blink which remind you to replace the battery timely.
*Sound prompt system
When the sound prompt system is enabled, different sound modes will prompt different working conditions of the speedlite so as to allow you to focus on shooting process (Note: the sound can be turned off).
*Equipped with the external power socket
YN-24EX is provided with external power socket to meet your higher demand of recycling time and no longer missing the wonderful moments.
*Automatic settings saving
YN-24EX can automatically save your current operating settings to convenient your next use.
Specification:
Circuit designInsulated Gate Bipolar Transistor (IGBT)
TypeAutomatic macro flash for close-up photography
Flash Ratio ControlTwo flash heads: 24/79, single flash head: 26/85 (ISO 100 105mm )
Flash Coveragevertical angle:Upwards,downwards 90 degrees
horizontal angle:inwards 60 degrees,outwards 30 degrees
The rotate degree of the adapter ring: upwards 50 degrees, downwards 30 degrees
Guide No.with the precision of 1/2 EV within the range of 8:1 - 1:1 - 1:8
Flash ModeTTL M
Recycle timeapprox 3s
Power supply4×AAsize batteries (Alkaline or Ni-MH are usable)
Lighting times200~2500 times (AA alkaline cell used)
Recycle timeapprox 3s (AA alkaline cell used)
Color temperature5600k
Flash time1/200s~1/20000s
Flash control8 levels of output control (1/128~1/1), 22 levels of fine tuning
External interfacehot shoe, PC port and external charging port
LED Color temperatureApporx. 5500K
LED luminance:Apporx. 300lux(1m)
Net weight998g
Compaible with :
for Canon 1Dx, 1Ds series, 1D series, 5DIII, 5DII, 7DII 5D, 6D, 7D, 80D, 70D, 60D, 50D, 40D, 30D, 20D, 750D 700D, 650D/T4i, 600D/T3i, 550D/T2i, 500D/T1i, 450D/Xsi, 400D/Xti, 350D, 100D, 1100D, 1000D, 1200D
Package including:
1 x Yongnuo YN24EX Macro Ring Flash
4 x Adapter Rings ( 52mm, 58mm, 67mm, 72mm )
1 x Moung Ring
1 x User Manual
1 x Original Protect Box
