Origin : CN(Origin)
Max. Resolution : 3840x2160
Certification : CE
Certification : FCC
Certification : RoHS
Package : Yes
Pixels : 8 Mega
Image Sensor : CMOS
Model Number : VA300B
Auto Focus : Yes
Interface Type : USB
Image Sensor : 1/2.8'4K UHD CMOS Sensor
Effective Pixels : 8.29MP 16:9
Video output port : USB-C
FOV : 120 Degree
Video Format : 4K3840*2160 30fps, 1920*1080P30fps/25fps, 1280*720P 30fps/25fps
Digital zoom : 5x
Auto framing : Yes
Audio input : 2 Microphones
Pickup Range : 5m
Expnasion Microphone Interface : USB3.0(VA300B)
Video Compression format : MJPG 30fps; H.264; H265.YUV
USB communication protocol : UVC, UAC
VA300B 4K EPTZ Camera with Auto-Framing Function USB PC Webcam with microphone and speaker 5X Digital Zoom EPTZ Web Cam 120° FOV
- USB3.0 video output
- 1/2.8'' 4K UHD CMOS Sensor
- 8 mega pixel (16:9 )
- 4K(3840 x 2160), 2K(2560*1440), 1080P(1920*1080)
- EPTZ with 5x Digital Zoom
- Built-in 2 MicrophoneS(VA300A)
- 2 Preset Positions(VA300A)
- Built-in microphones and Speaker(VA300B)
Adding 1 Expansion mic through USB-A Port(VA300B)
5M Voice Pickup Range
Webcam Parameter
Model |
VA300A |
VA300B |
Image Sensor |
1/2.8'' 4K UHD CMOS Sensor |
1/2.8'' 4K UHD CMOS Sensor |
Effective Pixels |
8.29MP 16:9 |
8.29MP 16:9 |
Video output port |
Type C |
Type C |
View Angle |
120° |
120° |
Video Format |
3840×[email protected]×1080P@30fps/25fps.1280×720P@30fps/25fps, etc |
3840×[email protected]×1080P@30fps/25fps.1280×720P@30fps/25fps, etc |
Min Illumination |
0.1Lux (F1.8, AGC ON) |
0.1Lux (F1.8, AGC ON) |
Lens Length |
f=2.02mm |
f=2.02mm |
Aperture |
F2.5 |
F2.5 |
Digital zoom |
5X |
5X |
DNR |
2D & 3D DNR |
2D & 3D DNR |
White Balance |
Auto / Manual |
Auto / Manual |
Focus |
Fixed |
Fixed |
SNR |
>55dB |
>55dB |
Audio Parameter |
||
Audio input |
Built-in 2 microphones |
Built-in 2 microphones |
Direction |
360 degree omnidirectional |
360 degree omnidirectional |
Pickup Range |
5M |
5M |
Audio Output |
No |
Built-in 1 high-performance speaker |
Audio Processing Technology |
Echo cancellation, noise suppression, automatic gain |
Echo cancellation, noise suppression, automatic gain |
Expnasion Microphone Interface |
USB-A |
USB-A |
USB Feature |
||
Operation Systems |
Windows 7(1080p at the most), Windows 8.1, Windows 10 ; macOS™ 10.10 or higher,Android, Linux (Require to support UVC.) |
Windows 7(1080p at the most), Windows 8.1, Windows 10 ; macOS™ 10.10 or higher,Android, Linux (Require to support UVC.) |
Video Compression format |
MJPG@30fps; H.264; H265.YUV |
MJPG@30fps; H.264; H.265 YUV |
USB communication protocol USB |
UVC, UAC |
UVC, UAC |
PTZ control PTZ |
Support EPTZ |
Support EPTZ |
Hardware requirement |
2.4 GHz Intel@ Core 2 Duo processor or higher,2GB RAM or more,USB 2.0 /USB3.0 port ( USB 3.0 is needed for 4K) |
2.4 GHz Intel@ Core 2 Duo processor or higher,2GB RAM or more,USB 2.0 /USB3.0 port ( USB 3.0 is needed for 4K) |
Other Parameters |
||
Input Voltage |
12V |
12V |
Input Current |
1A(Max.) |
1A(Max.) |
Power consumption |
12W/5W(Max.) |
12W(Max.) |
Store Temperature |
'-10℃～+60℃ |
'-10℃～+60℃ |
Store Humidity |
20%～90% |
20%～90% |
Working Temperature |
'-10℃～+50℃ |
'-10℃～+50℃ |
Working Humidity |
20%～80% |
20%～80% |
Accessory |
Webcam*1, USB3.0 Cable*1, Magnetic privacy cover*1, IR Remote*1, User Maual*1, Warranty card*1, |
Webcam*1, USB3.0 Cable*1, Magnetic privacy cover*1, IR Remote*1, AC Power adaptor, User Maual*1, Warranty card*1, |
What's in the box?
Webcam*1,
USB3.0 Cable*1,
Magnetic privacy cover*1,
IR Remote*1,
AC Power adaptor*1(VA300B)
User Maual*1,
Warranty card*1,
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops, pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc
