Compaible with:
for Canon 1Dx, 1Ds series, 1D series, 5DIII, 5DII, 7DII 5D, 6D, 7D, 80D, 70D, 60D, 50D, 40D, 30D, 20D, 750D 700D, 650D/T4i, 600D/T3i, 550D/T2i, 500D/T1i, 450D/Xsi, 400D/Xti, 350D, 100D, 1100D, 1000D, 1200D,550D,200D

Overview:
It's the YONGNUO first Macro TTL Flash Speedlite, it has two flash head, 4pcs Adapter rings £¨52mm, 58mm, 67mm, 72mm ), and mounting ring. Support E-TTL Flash, Exposure Compensation, FEB, Rear-curtain sync, FE Lock, Modeling Light, Canon camera MENU accessible, High brightness LED focus assist light to allow focus more easily.
Supports flash ratio, equipped with large-size LCD display, and the flash tube A and B can be adjusted together or individually, which can creates shadow on the subject to make the photo with engraving effect.
Sound prompt system, different sound modes will prompt different working conditions of the speedlite so as to allow you to focus on shooting process (Note: the sound can be turned off).
YN-24EX is equipped with standard PC synchronous interface which allows you convenient to use synchronous flash by using PC synchronous line, and the recycling time for full output just takes 3 seconds.
Automatic settings saving, YN-24EX is provided with external power socket to meet your higher demand of recycling time and no longer missing the wonderful moments.

Features:
Supports Master TTL Flash
Super Macro Flash
Large-size LCE Display
LED AF Assist Light
Equipped with PC sync interface
Sound prompt system
High Speed recycling system
Provided with the External Power Socket
Automatic Setting Saving
Low battery remind function

Specification:
Circuit Design: Insulate Gate Bipolar Transistor(IGBT)
Type: Automatic Macro Flash for Close-up Photography
Flash Ratio Control: 2 Flash Heads: 24/79, Single Flash Head: 26/85 (ISO 100 105mm)
Guide No.: GN24(ISO 100, 105mm)
Flash Mode: TTL/M
Recycle Time: Approx. 3s
Power Supply: 4 x AA size Batteris(Alkaline or Ni-MH Batteries)
Flash Times: 200-2500times(AA Alkaline)
Color Temperature: 5600K
Flash Duration: 1/200s - 1/20000s
Flash Control: 8 levels of output control, 22 levels of fine tuning
External Interface: Hotshoe, PC port and External Charging port
LED Luminance: Approx. 300lux(1m)
Net Weight: 1000g

Flash Coverage:
Vertical angle: Upwards,Downwards 90 degrees
Horizontal angle: Inwards 60 degrees,Outwards 30 degrees
The rotate degree of the adapter ring: upwards 50 degrees, downwards 30 degrees

Package Including:

• 1* YONGNUO YN24EX Macro Ring Flash

• 1* 4 Adapter Rings(52mm, 58mm, 67mm, 72mm)

• 1* Carrying Bag

• 1* User Manual
