Brand Name : TENVEO
Origin : CN(Origin)
Type : Video Conference System
Simultaneous Interpretation : No
Model Number : VA2000
Sensor : 1/2.7 inch HD Color CMOS
Effective Pixels : 2.1 mega pixel(16:9)
Video Format : 1080P30/25, 720P30/25
Optical zoom lens : 3x optical zoom, F=3.35mm(wide)-10.05(tele) F=1.6
View angle : Pan: 350°(max speed 80°/S), Tilt: 90°(max speed 60°/S)
Vvideo Compression Format : YUV, MJPG, H.264
Minimum Illumination : 0.5Lux(F1.8, AGC ON)
DNR : 2D&3D DNR
WDR : OFF/ Dynamic level adjustment
VA2000 Video Conferencing Kit 3x Zoom Cam with Speakerphone All in one conferencing solution for Living Video Collaboration
·UP TO 3-8 PEOPLE
·FULL HD1080P@30FPS
·128° field of view
·PAN AND TILT 3X HDZOOM
·4 OMNI-DIRECTIONAL MICS
·WORKS WITH ANY VIDEO MEETING APP
·All-in-one Video Conferencing GROUP
Main features
Complete audio/video conferencing group for small to medium rooms: HD video camera, speakerphone and optional expansion mics.
Maximum capacity up to 3-8 participants: Extended 10m(33 ft). audio range for medium to large group conferences
High end speakerphone with optional expansion mics: Plug & play HD audio allows everyone around the conference table to hear and be heard clearly
Easy and good video conferencing: Launch video meetings with a plug & play USB connection to a laptop and choose a video conferencing software
High def video: HD 1080p video with autofocus, 3x zoom lens. 128° wide view angle without distortion
Compatible with Mac and PC. System Requirements: Windows 7, 8.1 or 10,Mac OS X 10.7 or higher.
Use your video conference app of choice: Works with most UC, video conferencing and cloud communication apps
Pictures
Specification
Model NO. | TEVO-VA2000 PTZ camera |
Product Picture | |
Sensor | 1/2.7 inch HD Color CMOS |
Effective Pixels | 2.1 mega pixel(16:9) |
Video Format | 176x144/320x240/320x180/352x288/640x480/720x480/720x576/ |
Optical zoom lens | 3x optical zoom, F=3.35mm(wide)-10.05(tele) F=1.6 |
View angle | Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S) |
Aperture value | F=3.35mm(wide)-10.05(tele) F=1.6 |
Minimum Illumination | 0.5Lux(F1.8, AGC ON) |
DNR | 2D﹠3D DNR |
White Balance | Auto / Manual/ One Push/ |
Focus | Auto/Manual/One Push |
Aperture/Electronic Shutter | Auto/Manual |
BLC | ON/OFF |
WDR | OFF/ Dynamic level adjustment |
Video Adjustment | Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve |
SNR | >55dB |
Rotation angle | Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S) |
Control speed | Pan: 0.1 ～65°/sec, Tilt:0.1～35°/sec |
Preset speed | Pan: 65°/sec, Tilt: 35°/sec |
Dimensions | 151.64mm×131.25mm×154.5mm (L×W×H) |
Model NO. | TEVO-VA2000 Speakerphone |
Product Picture |
|
Voice technical parameters | Acoustic Echo cancellation（AEC）:>65dB |
Audio parameters | Microphone frequency response:100Hz-22KHz |
Bluetooth | Bluetooth devices available |
IR Reception | Angle: 360° |
Expansion Mic (optional) | 2 external microphones optional for connection makes the sound-pickup diameter up to 10 meters |
Dimensions | 200mm×200mm×52mm(L×W×H) |
Model NO. | TEVO-VA2000 Hub |
Product Picture |
|
Interface | Mini DIN6 ×2 |
Power supply | EC3800 plug(DC12V) |
Connection Cable | Mini DIN6 data line × 2 |
USB cable | USB2.0 cable |
Compatibility | Support Windows, Android, iOS and Linux |
Dimensions | 100mm×62mm×27mm(L×W×H) |
Accessories | Power adapter, USB2.0 cable, remote controller, 2 connection cables, user manual, |
What is in the box
1.Speakerphone
2.HD PTZ Camera
3.Hub
4.Remote Control
5.5m DIN6 Cable * 2 pcs
6.3m USB cable *1 pcs
7.Power supply
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops, pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
