Brand Name : TENVEO
Use : Audio / Video Players
Use : Camera / Video Camera
Certification : CE
Origin : CN(Origin)
Wireless Communication : IR
Support APP : No
Channel : 2
Package : Yes
Model Number : TENVEO KZ1 Controller
Product name : PTZ keyboard controller
Application : Application: Control video conference camera and Other PTZ Camera
TENVEO KZ1 Controller Joysticker PTZ Keyboard Controller Perfectly Fit for Tenveo Video Conference Camera Conference Keyboard
RS485 control bus, can control 255pcs head-end equipment address and connect 128pcs equipment in parallel at the most, as well as 7pcs series-connected SONY video conference camera
Can set and call 1-46 preset position of SONY video conference camera
All input and output communication port use anti-radar design,powerful anti-jamming performance, the standard transmitting distance is 1200 meters
Maximum sub-control keyboard:16
Good communication compatibility, built-in many kinds of protocols·
Keyboard operation password on/off/lock function
Key-press warning on/off function
Speed dome camera infinitely variable speed control
LCD display
Tips: How to use the Keyboard Controller to control upto 255pcs 20x Zoom PTZ Cameras, such as 20X Zoom TEVO-VHD203U or TEVO-VHD20N.
Step1. Use remote controller to set the address code of each camera separately: MENU-SYS SET-ADDRESS, Camera1:001, Camera2:002,* * *, CameraX:X.
Step2. Connect the control keyboard-camera 1-camera 2.... -cameraX in turn by using the network cable or RS485 signal line. RS-485 interface.
Step3. Setting the address code of each camera using the control keyboard:Setup-PASSWORD(8888)-CAM SET- Camera1:001, P(Protocol):PelcoD - enter - success. Setting the address codes of all other cameras by analogy,and set up the same communication protocol.
Step4. Controlling cameras by keyboard: Press the Addr button, then press 1 to control the camera1. Control the other cameras by analogy.
Highlight
Specially design for SONY video conference camera, completely compatible with VISCA protocol
Can set the address code of SONY video conference camera independently
Refurbish the program on line, compile corresponding promotion program according to the protocol and command provided by customer, customer connect keyboard controller through RS485 interface on the computer to update firmware
Unique control code learning function, customer can revise the control code command voluntarily
Multifold communication mode: RS485.RS422.RS232.10M internet (select to order), USB(select to order)
All parameters are set by key-press operation procedure, it is convenient and fast
Control the rotation of speed dome camera and swinging angle of joystick with nonpolar variable speed control to embody speed dome camera's rotating speed real-time.
Pictures
Specification
Model | TENVEO-KZ1 |
Protocol | Pelco-D, Pelco-P, VISCA |
Baud rate(bps） | 1200bps, 2400bps, 4800bps, 9600bps, 19200bps |
Control Address | Control 255pcs PTZ at the most, address code:0-254 |
Communication Mode | RS485 half-duplex, RS422 full-duplex, RS232 serial port |
RS232 serial port | |
Communication Range | RS485, RS422: 1200m, RS232: 10m |
Cascade connection number | 16 sub-control at most, controller ID:0-15 |
Joystick | 3D（control: up, down, left, right, zoom） |
Interface Mode | 10PIN pressing line port, DB9 connector |
Display | blue LCD |
Warning Tone | Key-touch beep on/off |
Power Supply | DC12V±10% |
Power Consumption | 6W MAX. |
Working Temperature | 0℃--50℃ |
Store Temperature | -20℃--70℃ |
Dimension (mm) | 320×179.3×109.9 |
Weight （Kg） | 2.8 |
Standard Package | 5pcs/ctn |
Package Weight | 22kg/ctn |
What is in the box
1 x Joysticker PTZ Keyboard Controller
1 x Rs232 cable
1 x Power adaptor
1 x User manual
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms, and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants, which could be 500 people dialing in from their laptops, pad or mobile phones, 500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
