Origin : CN(Origin)
Max. Resolution : 2560x2048
Certification : CE
Certification : FCC
Certification : RoHS
Package : Yes
Pixels : 5 Mega
Image Sensor : CMOS
Model Number : EVA200
Auto Focus : Yes
Interface Type : USB
Image Sensor : OS05A10 (1/2.8 inch SONY CMOS)
Effective pixel : 5.0 Megapixel
White balance : Auto
Back Light Compensation : Support
FPS : 30 fps (MJPG)Max
lris : F1.8
FOV : 165°
Zoom : Fixed(Support EPTZ, 4x Digital Zoom)
Video Output Format : MJPEG/H.264/YUV: 2560*1920; 1920*1080, 1280*720, 800*600, 640*360 YUY2: 1280*720,640*360
Special functions : OSD, EPTZ; 3xPresets
Video output interface : USB-C (USB2.0)
Microphone : Built-in omnidirectional analog microphone, 360-degree pickup range
Pickup range : 5 meters
Audio processing technology : ANS automatic noise suppression technology, AGC gain control adjustable technology
Transfer method : 1.5W MAX
Power supply : USB2.0 port provide power 5V 0.5A
Total power : Video: ZOOM+, ZOOM-, Up, Down, Left, Right, OSD Menu, Turn off camera
Status display : 16*colors LED indicator light (Annular Array); RGB 3*Colors Light
EVA200 EPTZ Webcam Auto Focus 4X Digital Zoom with Microphone 2.5k High Resolution Streaming Web Camera for Zoom Skype Teams
Tevo-EVA200 is integrated with a 2.5k EPTZ camera and microphone in one device. EVA200 uses OS05A10 5.0 Megapixel image sensor, which can provide 2.5K high-quality and ultra-clear images. The maximum resolution can reach 2.5K, and the output frame rate is up to 30 fps. It presents clear and realistic high-definition video, showing the expressions and actions of the characters vividly.
EVA200 webcam uses a 165° ultra-wide-angle, non-distortion camera; it supports 4 times digital zoom, built-in high-sensitivity 360° pickup digital microphone which has clear and natural sound effect, with excellent noise reduction algorithm, the pickup distance can reach up to 5 meters radius.
USB interface power supply, convenient and simple. Supports UVC, UAC protocol, USB interface, plug and play. It can be used in application scenarios such as personal video applications, video conferences, and collaborative work, etc.
-
2.5K Ultra HD image sensor, can support 2.5K high-quality and clear images
-
165° ultra-wide horizontal viewing angle
-
EPTZ function, 4X digital zoom with remote control
-
Built-in electret microphone, hands-free talk
-
USB(Type-C) interface, plug and play
-
3 Presets and autofocus
-
Free choices of installation location
-
Compatible with most video conferencing applications
*2.5K Ultra
HD-2.5K HD image sensor, can support 2K high-quality and clear images
Exquisite image effect, vivid picture, strong color hierarchy, high definition and color reproduction.
*Ultra-wide horizontal viewing angle
Support 165° ultra-wide horizontal field of view, Using a 165° ultra-wide-angle, non-distortion camera; it supports 4 times electronic zoom
*EPTZ function, 4X zoom
Support EPTZ function, zoom about 4 times, electronic pan/tilt movement and digital zoom function can be controlled by remote
*Built-in Microphone
Built-in high-sensitivity 360° pickup digital microphone, with excellent noise reduction algorithm, pickup distance up to 5 meters
*USB2.0 interface
plug and play-USB interface power supply, convenient and simple, supports UVC, UAC protocol, USB interface plug and play
Some real photos
| Video | ||
| Image Sensor | Image Sensor | OS05A10 (1/2.8″ SONY CMOS) |
| Effective pixel | 5.0 Megapixel | |
| White balance | Auto | |
| Gain Control | Auto | |
| Back Light Compensation | Support | |
| FPS | 30 fps (MJPG)Max | |
| S/N ratio | >50db | |
| Lens | Focus | 1.85mm±5% |
| lris | F1.8 | |
| Zoom | Fixed(Support EPTZ, 4x Digital Zoom) | |
| FOV | 165° | |
| Video Output Format | MJPEG/H.264/YUV: 2560*1920; 1920*1080, 1280*720, 800*600, 640*360 | |
| YUY2: 1280*720,640*360 | ||
| Special functions | OSD, EPTZ;3xPresets | |
| Video output interface | USB-C (USB2.0) | |
| Audio | ||
| Microphone | Built-in omnidirectional analog microphone, 360-degree pickup range | |
| Pickup range | 5 meters | |
| Audio processing technology | ANS automatic noise suppression technology, | |
| AGC gain control adjustable technology | ||
| Transfer method | USB2.0 | |
| Compatibility | ||
| OS Support | Windows 7 / 8 / 10; Mac OS 10.10 or higher | |
| Software Support | LCP (Zoom.BlueJeans.Broadsoft.Starleaf.Pexip.Vidyo),All of UVC Applications (Google Hangouts.Go to Meeting) | |
| Other Parameter | ||
| Protocol Agreement | UVC 1.0 | |
| Total power | 1.5W MAX | |
| Power supply | USB2.0 port provide power 5V 0.5A | |
| Remote functions | Video: ZOOM+, ZOOM-, Up, Down, Left, Right, OSD Menu, Turn off camera | |
| Status display | 16*colors LED indicator light (Annular Array); RGB 3*Colors Light | |
| Work Temperature | -40℃-50℃ (Storage temperature) | |
| -10℃ ~ 40℃ (Working temperature) | ||
| Humidity | 0-95% RH | |
| L x W x H | 262*85.5*110mm | |
| Weight | 330g | |
Conference Camera *1
USB 2.0 Cable(3m) *1
Remote Control(no battery) *1
User's Manual *1
Warranty Card*1
Bracket and screws *1
Tenveo Camera FAQQ:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops, pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
