Brand Name : TENVEO
Type : Standard Alone Camera
Supported Operating Systems : Windows 10
Supported Operating Systems : Windows 8
Supported Operating Systems : Windows 7
Supported Operating Systems : Mac OS
Supported Operating Systems : windows xp
High Definition : 1080P(Full-HD)
Lens (mm) : 8-32mm
Style : Dome Camera
Certification : CE
Certification : FCC
Certification : RoHS
Connectivity : USB
Smart home platform : NONE
Origin : CN(Origin)
Installation : Ceiling
Wall Bracket : Ceiling
Power Consumption(W) : 12 W
Color : black
Sensor : CMOS
Megapixels : 2MP
Sensor Brand : SONY
Special Features : Video Conference Camera
Storage : None
Power Supply : Normal
TF Card : None
IR Distance(m) : 10m
is_customized : Yes
Power Supply(V) : 1A
Model Number : TEVO-VHD203U
Viewing Angle : 60°
Technology : Pan Tilt Zoom
Dimensions (L x W x D)(mm) : 260*175*180 mm /296*255*238mm (before after packing)
Supported Mobile Systems : Android
Network Interface : RS-485
Audio Output : None
Sensor : 1/3'' type Exmor CMOS
Effective pixel : 2.38 mega pixel
Preset position : 255
Gain control : Auto,manual
Wide dynamic : D-WDR
Video output : USB, HDMI and SDI
Control terminal : RS232 RS485 RS422
Video output pixel : 1080P 1080i 720P
Signal standard : NTSC PAL
Lens : 20x optical zoom
Technology : Pan / Tilt / Zoom
With PTZ Keyboard Controller Tenveo HD 1080p60fps HDMI PTZ Video Conference Camera 20X Zoom USB HDMI Output Stream Webcam for Projector
Camera:
-
USB, HDMI and SDI Output
-
20X optical zoom
-
1/3'' type Exmor CMOS
-
2.38 mega pixel
-
HD1080P (1980x1080)
-
Pan: 0-340° Tilt :0°~120°
-
RS-232, RS-485, IR remote control
Ptz Controller:
-
RS485 control bus, can control 255pcs head-end equipment address and connect 128pcs equipment in parallel at the most, as well as 7pcs series-connected SONY video conference camera
-
Can set and call 1-46 preset position of SONY video conference camera
-
All input and output communication port use anti-radar design, powerful anti-jamming performance, the standard transmitting distance is 1200 meters
-
Maximum sub-control keyboard:16
-
Good communication compatibility, built-in many kinds of protocols·
-
Keyboard operation password on/off/lock function
-
Key-press warning on/off function
-
Speed dome camera infinitely variable speed control
-
LCD display
Tips: Press the Number(1-9) directly to call the reserved preset. Fast and Smooth
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
Highlight
-
20x optical zoom
-
USB, HDMI and Video Output
-
Sleek and intelligent design
-
Plug & Play USB Connectivity
-
Crystal clear HD1080P image quality
-
Accurate, smooth and silent PTZ Movement
-
Preset: 9 via IR remote setting (256 via RS232)
-
Wide field of view with no video distortion
-
1/3 inch high quality, 2.38MP (16:9) CMOS sensor
-
Superior quality with Full Glass Lens Material
-
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
-
2D and 3D NR for best video quality in different lighting conditions
-
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
-
Compatible with most leading video conferencing software and platform
Pictures
Specification
| Product No. | TEVO-VHD203U |
| Image Sensor | 1/3 inch HD CMOS |
| Effective pixel | 2.38 mega pixel（16:9） |
| Horizontal Resolution | 1080P60/50/30/25, 1080I60/50/30/25, 720P60/50 |
| Signal standard | NTSC/PAL |
| Zoom | 20x optical zoom |
| Focal length | F=4.7mm(wide)-94.0(tele) |
| Horizontal Angle | Near-end 55.5°～Far-end 3.0° |
| Gain control | Auto/manual |
| Focus | Auto/manual |
| SNR ratio | ≥50dB |
| Shutter speed | 1/1 sec to 1/10000s (22 steps) |
| Preset position | IR remote control supports 9 presets |
| Pan/Tilt movement range | Pan: 340°(max speed 80°/S), Tilt: 120°(max speed 60°/S) |
| Control terminal | RS-232, RS485 |
| Control Protocol | VISCA, PELCO-D, PELCO-P（RS-232,RS485） |
| Video output | USB, HDMI, SDI |
| Noise Reduction | 2D/3D |
| Work temperature | -10°C-~50°C |
| Storage temperature | -20°C~60°C |
| Baud rate | 2400/4800/9600/19200bps |
| Decoder | Built-in |
| Address set | 1~255 |
| Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
| Power supply | DC12 V/ 2A |
| Power consumption | 12 W |
| Net weight/Gross weight | 1.7kg/3.5kg |
| Dimension(LXWXH) | 260*175*180 mm /296*225*218mm(before / after packing) |
| Accessories | DC 12V Power adaptor, IR remote control, Manual, USB cable, Ceiling brackets & screws. |
| Model | TENVEO-KZ1 |
| Protocol | Pelco-D, Pelco-P, VISCA |
| Baud rate(bps） | 1200bps, 2400bps, 4800bps, 9600bps, 19200bps |
| Control Address | Control 255pcs PTZ at the most, address code:0-254 |
| Communication Mode | RS485 half-duplex, RS422 full-duplex |
| RS232 serial port | |
| Communication Range | RS485, RS422: 1200m, RS232: 10m |
| Cascade connection number | 16 sub-control at most, controller ID:0-15 |
| Joystick | 3D（control: up, down, left, right, zoom） |
| Interface Mode | 10PIN pressing line port, DB9 connector |
| Display | blue LCD |
| Warning Tone | Key-touch beep on/off |
| Power Supply | DC12V±10% |
| Power Consumption | 6W MAX. |
| Working Temperature | 0℃--50℃ |
| Store Temperature | -20℃--70℃ |
| Dimension (mm) | 320×179.3×109.9 |
| Weight （Kg） | 2.8 |
| Standard Package | 5pcs/ctn |
| Package Weight | 22kg/ctn |
What's in the box
1 x Camera
1 x DC 12Vpower adaptor
1 x IR remote control
1 x Manual
1 x USB cable
1 x Brackets & screws
1 x Joysticker PTZ Keyboard Controller
1 x Power supply
1 x User manual
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms, and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants, which could be 500 people dialing in from their laptops, pad or mobile phones, 500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, Easy meeting, Vidtel and working with Microsoft Lync Software,and ZOOM.US, SKYPE, VIDYO Etc.
