Specification
Model No. | TEVO-VHD20N |
Image Sensor | 1/3" CMOS |
Effective pixel | 2.38 mega pixel(16:9) |
Horizontal Resolution | 1080P60/50/30/25，1080i60/50,720P60/50 |
Focal length | F=5.5mm～110mm |
Signal standard | NTSC/PAL |
Zoom | 20x zoom |
Horizontal view angle | Near-end 54.7°～Far-end 3.3° |
Gain control | Auto/manual |
Focus | Auto/manual |
SN ratio | ≥50dB |
Shutter speed | 1/30 sec to 1/10,000s, auto |
Preset position | Remote-controller support 9 presets PELCO Control Protocol supports 255 presets |
Pan/Tilt movement range | Pan: 340°(max speed 80°/S), Tilt: 120°(max speed 60°/S) |
Control terminal | RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
Video output | USB,SDI, HDMI |
Noise Reduction | 2D/3D |
Work Temperature | -10°～50° |
Work Humidity | -20°～60° |
Baud rate | 34800/9600bps |
Decoder | Built-in |
Address Set | 1~255 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply | DC12V/2A |
Power | 12W |
Weight | 1.5kg/3.0kg |
Size | 260*175*180 mm /296*225*218mm (before / after packing) |
Accessories | DC 12V Power adaptor, IR remote control, Ceiling brackets & screws, Manual |
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software.For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces.You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops ,pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0,HDMI,HD-SDI,DVI,YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It’s compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh,WebEx, easy meeting, Vidtel and working with Microsoft Lync Software,and ZOOM.US, SKYPE, VIDYO Etc.
