Mars 400S PRO Product Description
Overview
MARS 400S PRO is using the latest coding, decoding technology, and 5G wireless transmission technology. It can achieve ultra-low latency wireless video transmission. It has a transmission range over 400ft with a clean line of sight (LOS) when the transmitter is connected to 1 or 2 receivers. MARS 400S PRO also can support 2 APPs monitoring when connection with 1 receiver. MARS 400S PRO is supports up to 1080P 60Hz image resolution. And Both transmitter and receiver equipped with L-series battery plate and also can power by DC adapter or power by USB-C interface.
Packing List
1. Transmitter x 1;
2. Receiver x 1;
3. Antenna x 5;
4. User Guide x 1;
5. DC Adapter x 1.
Key Features
1. Supports 1 Transmitter Connects With 2 Receivers
2. Supports Up To 2 Mobile Devices Monitoring While Only 1 Receiver Is Connected. Supports Up To 4 Mobile Devices Monitoring without Receiver connecting
3. OLED Display Screen
4. Channel Scan
5. Three Application Scene Modes
6. Battery Voltage Display
7. 400ft Transmission Range (LOS)
8. Lowest Latency is 0.08s
9. Both HDMI&SDI Connection Options
10. USB Firmware Upgrade
11.Integrated Cold Shoe for Quick Installation
12.Supports DC Power,USB Type-C Power Supply and Battery Power Supply.
Specifications
Transmitter
Receiver
Interface
HDMI-Input (Type A Female)
SDI Input
2 Antenna Interfaces (RP-SMA Male)
DC Input
Type-C USB
HDMI-Output (Type A Female)
SDI Output
2 Antenna Interfaces (RP-SMA Male)
DC Input,
Type-C USB
Supply Power Range
6~16V DC
USB Type-C Power Supply:5V/2A
6~16V DC
USB Type-C Power Supply:5V/2A
Power Consumption
<11W
<7W
Net Weight
206g
206g
Dimension
（L x W x H）: 110*72*33.5mm
External Antennas and Battery Plate Excluded
（L x W x H）: 110*72*33.5mm
External Antennas and Battery Plate Excluded
Input / Output Video Format
HDM-compatibleI:
480p60
576p50
720p50/59.94/60
1080i50/59.94/60
1080p23.98/24/25/29.9/30
1080P50/59.94/60
SDI:
1080P60/59.94/50(Level A)
1080P60/59.94/50(Level B)
1080i60/59.94/50
1080P30/29.97/25/24/23.98
1080Psf25
720P60/59.94/50
1080Psf24/23.98
HDMI-compatible:
480P60
576P50
720P50/60
1080i50/60
1080P24/25/30
1080P 50/60
SDI:
1080P60/50(Level A)
1080i60/50
1080P30/25/24
720P60/50
1080i50(1080Psf25/24/23.98 Input)
1080i60(1080Psf30/29.97 Input）
Frequency
5GHz
5GHz
Modulation Mode
OFDM
OFDM
Transmission Power
Maximum 21dBm
/
Receiver Sensitivity
/
-80dBm
Transmission Latency
0.08s
0.08s
Bandwidth
20MHz
20MHz
