Godox TT685O (TT685/O) TTL Camera Flash Photography External Flash For Olympus Panasonic Cameras
Description:
Godox TTL camera flash is compatible with TTL automatic flash. With built-in 2.4G radio transmission and TTL function, it is easy to deal with complex changes in light. It is compatible with master and slave wireless flash systems, multi-lights combined control, more professional.
Features:
Two transmission methods, wider range, more freedom to control light
- Optical transmission, uniform light distribution, stable output
- Built-in 2.4G wireless transmission, integrated transceiver, 100m/328.1ft ultra long distance, unlimited creativity
Master & Slave Flash
- As a main control unit, TT685O can work in four flash modes: TTL/M/Multi/OFF. Realize wireless TTL and manual flash
- As a slave unit, TT685O is compatible with XPro & X1 series transmitters. Realize wireless flash
TTL function is complete, unlimited enjoyment
- Fully support 1/8000s HSS high-speed synchronization, second-curtain shutter synchronization, exposure compensation, exposure bracketing, exposure lock, aperture preview, contrast flash and other functions
Godox TTL flash trigger XPro & X1, more outstanding functions
- XPro & X1 built-in 2.4G wireless transmission, can trigger the camera shutter, video flash and on-camera flash at a long distance (about 100meters/328.1ft)
- Fully support TTL automatic flash, manual flash, high-speed sync, exposure compensation, exposure lock, manual focus, modeling flash and other functions
- Wireless group remote control, remote synchronous triggering, to meet various shooting needs
- The large LCD screen clearly displays the parameters, which is convenient for photographers to flexibly arrange the light
Dot matrix LCD screen, easier to operate
- Adopt dot matrix LCD screen, large screen display, backlight light up, clear and intuitive
- 4 function buttons change prompts according to the setting of the flash, and the LCD screen clearly displays the operation content
- Turn the adjusting knob to easily set various parameters, which is convenient and practical
More advanced features
- GN60 (m ISO 100, at 200mm/7.9"), 22-level dimming (1/1~1/128)
- Recycle time is about 0.1-2.6s
- Support TTL/M/Multi/S1/S2 multi-mode, lamp holder 20-200mm/0.8-7.9" automatic or manual focusing
- With custom advanced option settings
- USB firmware upgrade
- Wireless control socket/sync jack/USB interface
Specifications:
- Model: TT685O
- Compatible cameras: for Olympus/Panasonic cameras
- Guide number (1/1 gear; 200mm/7.9" focal length): 60 (m ISO 100), 190 (feet ISO 100)
- Flash coverage:
* 20-200mm/0.8-7.9" (14mm/0.6" with wide-angle diffuser) (TT685C/TT685N/TT685S)
* 20-200mm/0.8-7.9" (135 system) or 14-133mm/0.6-5.2" (APS) (TT685F/TT685O)
* Automatic zoom (automatically set flash coverage suitable for lens focal length and image size)
* Manual zoom. Flash head rotation/tilt, horizontal 0 to 360°, vertical -7° to 90° (bounce flash)
- Flash duration: 1/300 second-1/20000 second
Exposure Control:
- Exposure control system: TTL automatic flash, manual flash
- Flash Exposure Compensation (FEC): Manual, Flash Bracketing: Adjust in 1/3 steps between ±3 steps (manual flash exposure compensation and flash bracketing can be used in combination)
- Flash Exposure Lock (FEL): / (without)
- Synchronization mode: high-speed synchronization (up to 1/8000 seconds), front-curtain synchronization, rear-curtain synchronization
- Stroboscopic flash: With (number of times: 100 times; 200Hz)
Wireless Flash:
- Wireless function: master unit, slave unit, off
- Controllable slave unit group: * 3 groups, A, B, C (TT685C/TT685N/TT685F/TT685O). * Optics: 2 groups (A, B); 2.4G: 3 groups (A, B, C) (TT685S)
- Transmission range (approximately): * Optical: / (Without). * 2.4G: 100m/328.1ft
- Channel: * Optical: / (Without). * 2.4G: 32 groups (1~32)
- Slave unit status indicator: Two red lights are on at the same time
- Modeling flash: / (Without)
Autofocus Auxiliary Light:
- Effective range (approximately): Center: 0.6-10m/2-32.8ft; Edge: 0.6-5m/2-16.4ft
Others:
- Recycle time: about 0.1-2.6 seconds
- Energy saving: The flash will automatically power off after about 90 seconds of unattended operation. 60 minutes into sleep state when set as a slave unit
- Synchronous trigger mode: hot shoe, 3.5mm sync line, wireless control socket
- Color temperature: 5600±200k
- Volume: 64 x 76 x 190mm/2.5 x 3 x 7.5"
- Net weight: 410g/0.9 lb
Package Included:
- 1 x Set of Camera Flash
Note:
- Batteries are not included. 4pcs Ni-MH batteries (recommended) or 4pcs LR6 alkaline batteries can be used.
