Origin : CN(Origin)
Type : Video Conference System
Simultaneous Interpretation : No
Model Number : NV4K
Image Sensor : 1/2.1 inch HD Color CMOS
Effective pixel : 8.29 mega pixel (16:9)
Horizontal Resolution : 4K (3840 x 2160), 2K(2560*1440), 1080P(1920 x 1080)
Lens : F= 2.1mm
Field of View : Fixed focus, Diagonal :138 °, Horizontal: 120 °, Vertical: 100 °
Control Protocol : VISCA, PELCO-D, PELCO-P (RS-232, RS485)
HD Video output : USB plug and play
Baud rate : 38400/9600bps
Decoder : Built-in
Installation : Support desktop, Tripod, Wall mount and Ceiling mount
Power supply : DC12V/2A
Power : 12W
FPS : 4K at 30FPS
NV4K Utral 4k 30fps Video Conference Camera USB Plug and Play Fixed Cam 138° Wide View Angle for Tele-Medicine interview
TEVO-NV4K comes with an Ultra-HD imaging system, Rally delivers brilliantly sharp video, outstanding color, and exceptional optical accuracy at resolutions up to 4K. This camera adopts1/2.7 inch HD Color CMOS, 8.29 effective mage pixel, 138 °super-wide field of view, to emphasize faces and render natural-looking skin tones, even in dim or backlit conditions. NV4K meets with the application for Ultra HD recording and streaming, video conferencing, and broadcasting that supports USB cameras.
Main featuresAutomatic camera control
1/2.7 inch HD Color CMOS
4k(3840X2160 )Ultra HD video resolution
Preset: 9 via IR remote setting (255 via RS232)
Equipped with IR remote control, easy to operate
High precise motor positioning (Pan:350°,Tilt: 90°)
UVC/plug-and-play at MJPEG via USB, 4K@30FPS
Support ceiling mount, wall mount and tripod mount
138 degrees Wide field of view with no video distortion
Quiet & smooth mechanism movement, accurate & fast focus
Support Visca, Pelco-P&Pelco-D protocol, RS232/RS485 Camera Control
Compatible with most leading video conferencing software and platform
Specification
Item No. | TEVO-NV4K |
Image Sensor | 1/2.7″CMOS（SONY IMX274） |
Effective pixel | 8.29 mega pixel（16:9） |
Horizontal Resolution | 4K(3840 x 2160), 2K(2560*1440), 1080P(1920*1080) |
Signal standard | N TSC/P AL |
Lens | Fixed focus 2.1mm wide angle lens |
Field of View: | Fixed focus, Diagonal :138 °, Horizontal: 120 °, Vertical: 100 ° |
SNR ratio | ≥50dB |
Preset position | Remote-controller supports 9 presets, |
Pan movement range | Pan: ±175°(max speed 80°/S) |
Tilt movement range | -35°~﹢55°(max speed 60°/S) |
Control terminal | RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
HD Video output | USB plug and play |
Work Temperature | -10°～50° |
Work Humidity | -20°～60° |
Baud rate | 38400/9600bps |
Decoder | Built-in |
Address Set | 1~64 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply | DC12V/2A |
Power | 12W |
Weight | 1.5kg/2.85kg(before / after packing) |
Size | 162*172*175mm /257*220*210mm (before / after packing) |
Accessories | DC 12V Power adaptor, IR remote control, Ceiling brackets & screws, Manual, USB cable |
1 x NV4K Camera
1 x DC 12V Power adaptor
1 x IR remote control
1 x Ceiling brackets & screws
1 x Manual
1 x USB cable
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops, pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
