Origin : CN(Origin)
Package : Yes
Model Number : AVMATRIX VS0601U
AVMATRIX VS0601U MINI 6 CHANNEL MULTI-FORMAT STREAMING SWITCHER
Uncompressed capture for live streaming, comply with UVC & UAC.
6 channel inputs: 4×SDI & 2×HDMI.
1×USB type-C out, 2×SDI & 1×HDMI PGM outputs, 1×SDI & 1×HDMI multiview outputs.
1×SDI AUX output, can be selected as PGM or PVW.
Multi-format input auto-detected and PGM outputs format selectable.
T-Bar/ AUTO/ CUT transitions & Mix/ Fade/ Wipe transition effects.
PIP mode size and position adjustable.
Support audio MIXING and AFV mode.
GPIO for Tally, FTB for emergency.
USB Capture For Streaming
The new PVS0613U features with an added built-in USB Type-C output, when connecting with PC, it will work like a webcam for capturing uncompressed video and audio quality and streaming your production to various software and platform like Twitch, Youtube, Facebook LIVE, Zoom, etc. No driver needed, and compatible with Windows 7/8/10, Linux and Mac OS.
Widespread Application
The all-in-one 6 channel video switcher can be widely used in various field events, such as live sports, virtual studio, education, church, internet, concert, and so on.
Super Compact Design
Outstanding metal case architectonics, with only 1.2kg weight. Convenient and suitable for the application of various occasions. 4 x SDI and 2 x HDMI inputs, 2 x SDI & 1 x HDMI PGM outputs, 1 x SDI AUX output for PVW & PGM, USB Type-C 3.0 output, 1 x SDI & 1 x HDMI multiview output.
