Designed to wirelessly control multiple lights in the Nanlite line, the NANLINK Transmitter Box is a 2400 MHz battery-driven unit that allows you to charge it while running on AC power. Bottom 1/4"-20 threads, a side belt clip, and a ring integrated into the chassis offer different ways to mount it. The included padded case has a belt loop and a carabiner clip. The NANLINK Transmitter Box is compatible with PavoTube II X-Series, PavoTube 30C and 15C, PavoTube II 6C, Forza 500, 300, 300B, 200, 150, 60, and 60B, MixPanel 150 and 60, FS 300, 200, and 150, LumiPad 25 and 11, Compac 200, and more.

Wireless Control

Wirelessly control lights with the NANLINK mobile app regardless of whether they have built-in Bluetooth. Any Nanlite fixture with built-in 2.4 GHz is compatible with the NANLINK, including the PavoTube 30C and 15C, Forza 500, MixPanel 150 and 60, and others. The NANLINK mobile app gives you deep control over color temperature, HSI, and effects, and it lets you easily create repeatable scenes and presets and control lights in groups.

Multiple Power Options

With a built-in 2400 MHz battery, the NANLINK Transmitter Box can run for 10 hours. The integrated USB Type-C port allows you to add future firmware updates, but it also lets you power the device in the field with a USB power bank battery. You can also use this port to connect the NANLINK directly to an AC outlet to run continuously while charging the internal battery.

Compact and Easy to Mount

The NANLINK was designed to be as compact and lightweight as possible while providing all-day battery life and a robust control signal. An internal antenna system helps it perform and keeps the size to a minimum. A bottom 1/4"-20 thread, side belt-clip, and ring integrated into the chassis give you many ways to mount it. The included padded case even has a belt loop and carabiner clip.

Compatible with Many Lights

The NANLINK is fully compatible with the PavoTube II X-Series, PavoTube 30C and 15C, PavoTube II 6C, Forza 500, 300, 300B, 200, 150, 60, and 60B, MixPanel 150 and 60, FS 300, 200, and 150, LumiPad 25 and 11, Compac 200, and more.

What you need to get started

You are going to need a USB 2.0 drive that you can connect to the USB-C port on the WS-TB-1 in order to carry out this firmware update. Nanlite USA is including a USB 2.0 drive in the box of the WS-TB-1 with the latest firmware update preloaded onto the included drive. If you received one of these drives with your WS-TB-1, you don't need to download the firmware and load it on to the drive. You can skip right to the numbered instructions below.

Where to download the latest firmware

If you need to download the firmware, you can find it at this link:

http://www.nanlink.com/en/h-col-234.html

The file that you download from that link will be zipped. You need to unzip it first. Then you need to move the file named WS_TB_1_FW_V1.01.05.upd to your USB 2.0 drive. Do not keep any other files in the drive when you carry out the firmware update, only the "upd" file that you downloaded.

How to load the firmware onto the NANLINK WS-TB-1

1. Insert the drive into the USB-C port on the WS-TB-1 Transmitter Box

2. Switch on the power switch.

3. Long press the function button for 5 seconds after the indicators flash rapidly in sync.

4. During the upgrade process, the indicators will flash like breathe.

5. The indicators will return to normal after the upgrade is completed successfully.

NOTICE: If the two indicators in the middle light up and the other two indicators outside light up after, it means that the box fails to detect the firmware upgrade, please check the instruction steps the try again.

We hope that this post has been helpful. If you need any assistance updating your WS-TB-1 Transmitter Box, please contact us and we will respond quickly. Taking care of our customers is our top priority.
