Brand Name : TENVEO
Origin : CN(Origin)
Type : Video Conference System
Simultaneous Interpretation : No
Function : Voting
Model Number : VA3000E
Sensor : 1/2.9 inch high quality HD CMOS sensor
Effective Pixels : 2.07 Mega pixel, 16:9
Video Format : 1080P30/25/20/15/10/5
Optical zoom lens : 10x optical zoom, 4.7-47mm
View angle : 20 Degree(tele) 90 Degree (wide)
Aperture value : F1.8 - F2.8
Minimum Illumination : 0.5Lux(F1.8, AGC ON)
DNR : 2D&3D DNR
WDR : OFF/ Dynamic level adjustment

Free Shipping & Ready to ship VA3000E Speakerphone & Conference Camera Support 2 External Mics for Video Conference System

·UP TO 25 PEOPLE

·FULL HD1080P@30FPS

·51.3° field of view

·PAN AND TILT 10X HDZOOM

·4 OMNI-DIRECTIONAL MICS

·WORKS WITH ANY VIDEO MEETING APP

·All-in-one Video Conferencing GROUP

·With 2 Expansion mics



Main features

• Complete audio/video conferencing group for medium to large rooms: HD video camera, speakerphone and optional expansion mics.

• Maximum capacity up to 25 participants: Extended 10m(33 ft). audio range and 51.3-degree field of view for medium to large group conferences

• High end speakerphone with optional expansion mics: Plug & play HD audio allows everyone around the conference table to hear and be heard clearly

• Easy and good video conferencing: Launch video meetings with a plug & play USB connection to a laptop and choose a video conferencing software

• High def video: HD 1080p video with autofocus, 10x zoom lens. 51.3 ° wide view angle without distortion, 6 Preset Positions

• Compatible with Mac and PC. System Requirements: Windows 7, 8.1 or 10,Mac OS X 10.7 or higher.

• Use your video conference app of choice: Works with most UC, video conferencing and cloud communication apps

Pictures

Specification

Model NO.	TEVO-VA3000 PTZ camera
Product Picture
Sensor	1/2.9 inch high quality HD CMOS sensor
Effective Pixels	2.07Mega pixel, 16:9
Video Format	176x144/320x240/320x180/352x288/640x480/720x480/720x576/ 640x360/800X600/960X540/1024X576/1024X768/1280X720/ 1920X1080P30/25/20/15/10/5
Optical zoom lens	10x optical zoom, f＝4.7～47mm
View angle	20°（tele） 51.3°（wide）
Aperture value	F1.8 – F2.8
Minimum Illumination	0.5Lux(F1.8, AGC ON)
DNR	2D﹠3D DNR
White Balance	Auto / Manual/ One Push/ 3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
Focus	Auto/Manual/One Push
Aperture/Electronic Shutter	Auto/Manual
BLC	ON/OFF
WDR	OFF/ Dynamic level adjustment
Video Adjustment	Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR	>55dB
Rotation angle	Pan: -125°～+125°, Tilt:-30°～+30°
Control speed	Pan: 0.1 ～65°/sec, Tilt:0.1～35°/sec
Preset speed	Pan: 65°/sec, Tilt: 35°/sec
Dimensions	151.64mm×131.25mm×154.5mm (L×W×H)

Model NO.	TEVO-VA3000 Speakerphone
Product Picture
Voice technical parameters	Acoustic Echo cancellation（AEC）:>65dB Echo length cancellation:≥400ms Bidirectional noise compression（NC）:<25dB Automatic Direction finding Technology of Intelligent microphone（EMI） Automatic gain control（AGC）
Audio parameters	Microphone frequency response:100Hz-22KHz Speaker frequency response:100Hz-22KHz Speaker volume: 95dB at the most Microphone sound-pickup diameter: 6 meters, 360 degrees full range
Bluetooth	Bluetooth devices available

IR Reception	Angle: 360° Distance: 10m IR Transparent transmission available
Expansion Mic (optional)	2 external microphones optional for connection makes the sound-pickup diameter up to 10 meters
Dimensions	200mm×200mm×52mm(L×W×H)
Model NO.	TEVO-VA3000 Hub
Product Picture
Interface	Mini DIN6 ×2 Power interface × 1 Power switch × 1 Mini USB interface × 1
Power supply	EC3800 plug(DC12V) Adapter input AC110V-AC220V,output DC12V/1.5A
Connection Cable	Mini DIN6 data line × 2 Length: 5m（10m/15m for options）
USB cable	USB cable
Compatibility	Support Windows, Android, iOS and Linux Drive-free automatic recognition of cameras, microphones and speakers Compatible with Zoom, Lynch, Vidyo, Skype for business and etc.
Dimensions	100mm×62mm×27mm(L×W×H)
Accessories	Power adapter, USB cable, remote controller, 2 connection cables, user manual,

What is in the box     1.Speakerphone 2.HD PTZ Camera 3.Hub 4.Remote Control 5.5m DIN6 Cable * 2 pcs 6.3m USB cable *1 pcs 7.Power supply 8.2 Expansion mics     Tenveo Camera FAQ

Q:What kind of camera should I use?

A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.

Q:Is it easy to operation?

A:Yes, it is easy to install, plug and play.

Q:Can I bring more than one person into a call at the same time?

A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops, pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.

Q:What is the resolution of your cameras?

A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.

Q:What is the Video Connector?

A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.

Q:How many time zoom?

A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.

Q:How to control this Camera?

A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.

Q:Which kind of software compatible with this Camera?

A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
