Brand Name : TENVEO
Supported Operating Systems : Windows 10
Supported Operating Systems : Windows 2000
Supported Operating Systems : Windows 8
Supported Operating Systems : Windows 7
Supported Operating Systems : Windows 98
Supported Operating Systems : Mac OS
Supported Operating Systems : windows xp
Origin : CN(Origin)
High Definition : 1080P(Full-HD)
Lens (mm) : 4mm
Style : Dome Camera
Connectivity : 3G-SDI HDMIUSB
Installation : Side
Minimum Illumination(Lux) : None
Megapixels : 2MP
Special Features : Vandal-proof
Storage : None
Video Compression Format : H.264
TF Card : None
IR Distance(m) : 10M
Power Supply(V) : 12W
Certification : CE
Certification : FCC
Certification : RoHS
Dimensions (L x W x D)(mm) : 162*172*175 mm /257*220*210mm (before / after packing)
Audio Output : HDMI
Power Consumption(W) : DC12V/2A
Color : Black
Sensor : CMOS
Sensor Brand : Panasonic
Power Supply : Normal
is_customized : Yes
Model Number : TEVO-NV20A
Viewing Angle : 60°
Supported Mobile Systems : Android
Smart home platform : NONE
Image Sensor : 1/3 inch type Exmor CMOS
Lens : F=5.5mm(wide)-110(tele)
Zoom : 20x zoom
Effective pixel : 2.38 mega pixel(6:9)
Horizontal Angle : Near-end 54.7°-Far-end 3.3°
Pan movement speed : 350 dgree (100 dgree/S)
Minimum illumination : 0.25Lx(on)
Color : Black
Style : SDI Camera
Technology : Pan/Tilt/Zoom
[EU Stock] Tenveo NV20A 1080p PTZ Conference Camera 20X Zoom USB Conference Cam HDMI SDI Output for Church Livestream Education
20x optical zoom, 1/3 inch high quality, 2.1MP (16:9) CMOS sensor
HDMI USB 3G-SDI 3 Outputs Simultaneous
Crystal clear HD 1080P image quality, superior quality with full glass lens material
2D and 3D NR for best video quality in different lighting conditions
Accurate, smooth, and silent PTZ movement
Preset: 0-9 via IR remote setting (255 via RS232)
Easier 360° remote control thanks to IR receivers on the front and back of the PTZ camera
Support Visca, Pelco-P, and Pelco-D control, RS232/RS485 camera control
Plug and play USB connectivity, easy to setup
Compatible with many popular applications and cloud system
Video Compression Format supports YUV, MJPG, H.264
Image Flip and Image Mirror. Press MENU - IMAGE - Mirror, and adjust Left/Right/UP/DOWN to manipulate image flip and Mirror.
ACCURATE, SMOOTH, AND SILENT PTZ MOVEMENT
Along with 350-degree pan & 90 degrees tilt rotation at a fast speed & accurate focus to capture any view in conferencing space.
HDMI USB 3G-SDI 3 Outputs Simultaneous:
SDI: SDI Can connect to your SDI Video capture (blackmagic). The effective transmission distance of 3G-SDI Cable is 328ft(100m+).
USB: USB plug and play. Any one can easily setup and connect to your USB PC, Desktop or laptop and control this PTZ Camera. USB cable support 66ft(20m) HD Video transfer
HDMI: HDMI can connect to your smart TV, Monitor or Interactive Whiteboard and supports 98ft(30m) HD Video transfer.
RS-232: RS-232 Slot, support VISCA/PELCO-D/PELCO-P Protocol, and support up to 10 meters RS232 cable control.
RS- 485: RS-485 slot, support VISCA/PELCO-D/PELCO-P Protocol and PELCO-P Protocol and RS485 control cable.
IR Remote Supports 10 presets:
Tips: Press the Number(0-9) directly to call the reserved preset. Fast and Smooth
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
COMPATIBLE WITH POPULAR PC, MAC, LAPTOP, AND CONFERENCE APPS,
This webcam is compatible with Windows XP, Vista, 7/8/8.1, and 10, Mac 10.4 or higher, and laptops, LCDs, and monitors. It's compatible with any online conferencing software, including Zoom, Skype, and Google Hangouts, Cisco WebEx, Microsoft Team, GoToMeeting, BlueJeans and etc.
Camera Parameters:
Model No. |
TEVO-NV20A |
Image Sensor |
1/3'' CMOS |
Effective pixel |
2.38 mega pixel(16:9) |
Horizontal Resolution |
1080P60/50/30/25, 1080i60/50, 720P60/50 |
Focal length |
F=5.5mm(wide)-110(tele) |
Signal standard |
NTSC/PAL |
Zoom |
20x zoom |
Horizontal view angle |
Near-end 54.7°～Far-end 3.3° |
Gain control |
Auto/manual |
Focus |
Auto/manual |
SN ratio |
≥50dB |
Shutter speed |
1/30 sec to 1/10,000s, auto |
Preset position |
Remote-controller support 10 presets PELCO Control Protocol supports 255 presets |
Pan/Tilt movement range |
Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S) |
Control terminal |
RS-232, RS485 |
Control Protocol |
VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
Video output |
USB, SDI, HDMI |
Noise Reduction |
2D/3D |
Work Temperature |
-10°～50° |
Work Humidity |
-20°～60° |
Baud rate |
34800/9600bps |
Decoder |
Built-in |
Address Set |
1~64 |
Installation |
Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply |
DC12V/2A |
Power |
12W |
Weight |
1.5kg/2.85kg(before / after packing) |
Size |
162*172*175mm /257*220*210mm (before / after packing) |
Accessories |
DC 12V Power adaptor, IR remote control, Ceiling brackets & screws, Manual |
What's in the Box?
- 1 X Camera
- 1 X USB Cable
- 1 X DC 12V power adaptor
- 1 X IR remote control
- 1 X Celling Brackets
- 1 X Manual
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software.For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces.You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops ,pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0,HDMI,HD-SDI,DVI,YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh,WebEx, easy meeting, Vidtel and working with Microsoft Lync Software,and ZOOM.US, SKYPE, VIDYO Etc.
