Brand Name : TENVEO
Origin : CN(Origin)
Type : Video Conference System
Simultaneous Interpretation : No
Function : video conference
Model Number : TEVO-NV20U
Sensor : 1/3'' type Exmor CMOS
Effective pixel : 2.1 mega pixel
Preset position : 255
Gain control : Auto,manual
Wide dynamic : D-WDR
Video output : USB2.0
Control terminal : RS232 RS485 RS422
Video output pixel : 1080P 720P
Signal standard : NTSC PAL
Lens : 20x optical zoom
Support : YUV, MJPG, H.264
Tenveo NV20U 2MP 20x Zoom USB PTZ Video Conference Camera HD 1080p USB Plug and Play Camera Pan Tilt Zoom For Teleconference
USB2.0 video output
1/3'' Exmor CMOS
2.1 mega pixel
HD1080P
20X optical zoom
Pan: 350° Tilt :90
°
Support RS-232, RS-485,
With IR remote control
Tips: Press the Number(1-9) directly to call the reserved preset. Fast and Smooth
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
Highight
20x optical zoom
Sleek and intelligent design
Plug & Play USB2.0 Connectivity
Crystal clear HD1080P image quality
Preset: 9 via IR remote setting (255 via RS232)
Wide field of view with no video distortion
1/3 inch high quality, 2.1MP (16:9) CMOS sensor
Superior quality with Full Glass Lens Material
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
2D and 3D NR for best video quality in different lighting conditions
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
Compatible with most leading video conferencing software and platform
Utilizing belt drive technology the PTZ is ultra-quiet and fast, while being very smooth
Pictures
Specification
Product No. | TEVO-NV20U |
Image Sensor | 1/3 inch Exmor CMOS |
Effective pixel | 2.1 mega pixel（16:9） |
Horizontal Resolution | 1080p30/25, 720p30/25 |
Signal standard | NTSC/PAL |
Zoom | 20x optical zoom |
Focal length | F=5.0mm(wide)-50.0(tele) F=1.8(W)-2.1(T) |
Horizontal Angle | Near-end 55.5°～Far-end 3.0° |
Gain control | Auto/manual |
Focus | Auto/manual |
SNR ratio | ≥50dB |
Wide dynamic | D-WDR |
Shutter speed | 8to1/ 10000s(auto) |
Preset position | IR remote control supports 9 presets |
Pan/Tilt movement range | Pan: 350°(max speed 100°/S), Tilt: 90°(max speed 80°/S) |
Control terminal | RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P（RS-232, RS485） |
Video output | USB |
Noise Reduction | 2D/3D |
Work temperature | -10°C-~50°C |
Storage temperature | -20°C~60°C |
Baud rate | 2400/4800/9600/19200bps |
Decoder | Built-in |
Address set | 1~64 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply | DC12 V/ 2A |
Power consumption | 12 W |
Net weight/Gross weight | 1.5kg/2.85kg(before / after packing) |
Dimension(LXWXH) | 162*172*175mm /257*220*210mm (before / after packing) |
Accessories | DC 12V Power adaptor, IR remote control, Manual, USB 2.0 cable, Ceiling brackets & screws. |
What's in the box
1 x Camera
1 x DC/12V power adaptor
1 x IR remote control
1 x Manual
1 x USB cable
1 x Brackets & screws
1 x Warranty
1 xCertificate of qualification
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants, which could be 500 people dialing in from their laptops, pad or mobile phones, 500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, Easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
