Brand Name : TENVEO
Certification : CE
Certification : FCC
Certification : RoHS
Max. Resolution : 1920x1080
Origin : CN(Origin)
Model Number : VHD1080 PRO
Auto Focus : Yes
Package : Yes
Interface Type : USB
Pixels : 2 Mega
Image Sensor : CMOS
Image Sensor : 1/2.7 inch HD Color CMOS
Effective pixel : 8.0 mega pixel
Horizontal Resolution : 1920x1080p 25/30fps / 1280x720p 25/30fps
Zoom : Fixed Focus Wide Angle
Lens : 2.1mm
Horizontal Angle : 138 Degree
Wide dynamic : D-WDR
Pan/Tilt movement range : Pan: 340°(max speed 80°/S), Tilt: 120°(max speed 60°/S)
Support : YUV, MJPG, H.264
Tenveo VHD1080 Pro 8MP Fixed Camera Full HD 1080P PTZ Camera USB Conference camera Pan Tilt Zoom 138 Degree Fixed Focus
USB2.0 video output
1/2.7'' HD Color CMOS
8.0 mega pixel
138 degree Fixed focus wide angle
Pan: 350°(max speed 80°/S), Tilt: 90°(max speed 60°/S)
RS-232,RS-485,IR remote control
Supports YUV, MJPG, H.264
Tips: Press the Number(1-9) directly to call the reserved preset. Fast and Smooth
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
Highlight
-
Fixed focus Pan Tilt Camera
-
Sleek and intelligent design
-
Plug & Play USB Connectivity
-
Crystal clear HD1080P image quality
-
Accurate, smooth and silent PTZ Movement
-
Preset: 9 via IR remote setting (255 via RS232)
-
Superior quality with Full Glass Lens Material
-
138° wide field of view with no video distortion
-
1/2.7 inch high quality, 8 MEGA PIXEL (16:9) CMOS sensor
-
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
-
2D and 3D NR for best video quality in different lighting conditions
-
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
-
Compatible with most leading video conferencing software and platform
-
Pictures
Specification
Product No. |
TEVO-VHD1080 Pro |
Image Sensor |
1/2.7 inch HD Color CMOS |
Effective pixel |
8.0 mega pixel |
Horizontal Resolution |
1080P30/25, 720P30/25, VGA(640x480), CIF(352x288) |
Signal standard |
NTSC/PAL |
Zoom |
Fixed focus |
Focal length |
F=2.1mm |
Horizontal Angle |
Diagonal :138 °, Horizontal: 120 °, Vertical: 100 ° |
Gain control/Focus |
Auto/manual |
SNR ratio |
≥50dB |
Wide dynamic |
On/Off |
Shutter speed |
8 to 1/10000s (auto) |
Preset position |
IR remote control supports 9 presets |
Pan/Tilt movement range |
Pan: 340°(max speed 80°/S), Tilt: 120(max speed 60°/S) |
Control terminal |
RS-232, RS485 |
Control Protocol |
VISCA, PELCO-D, PELCO-P（RS-232, RS485） |
Video output |
USB |
Video Compression Format |
YUV, MJPEG, H.264 |
Noise Reduction |
2D/3D |
Work temperature |
-10°C-~50°C |
Storage temperature |
-20°C~60°C |
Baud rate |
38400/9600bps |
Decoder |
Built-in |
Address set |
1~255 |
Installation |
Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply |
DC12 V/ 2A |
Power consumption |
12 W |
Net weight/Gross weight |
1.46kg/2.8kg(before / after packing) |
Dimension(LXWXH) |
162*172*175mm /257*220*210mm (before / after packing) |
Accessories |
DC 12V Power adaptor, IR remote control, Manual, USB cable, Ceiling brackets & screw |
What's in the box
1 x Camera
1 x DC/12V power adaptor
1 x IR remote control
1 x Manual
1 x USB cable
1 x Brackets & screws
1 x Warranty card
1 x Certificate of qualification
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms, and large auditorium spaces. You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants, which could be 500 people dialing in from their laptops, pad or mobile phones, 500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
