Brand Name : TENVEO
Type : ip camera
Supported Operating Systems : Windows 10
Supported Operating Systems : Windows 8
Supported Operating Systems : Windows 7
Supported Operating Systems : windows xp
High Definition : 1080P(Full-HD)
Lens (mm) : 4mm
Style : Dome Camera
Certification : CE
Certification : FCC
Certification : RoHS
Connectivity : USB
Smart home platform : NONE
Origin : CN(Origin)
Installation : Ceiling
Wall Bracket : Ceiling
Power Consumption(W) : 12V
Color : Black
Sensor : CMOS
Megapixels : 2MP
Sensor Brand : SONY
Special Features : 3x Optical Zoom
Storage : None
Power Supply : Normal
TF Card : None
is_customized : Yes
Power Supply(V) : 2A
Model Number : TEVO-NV3U
Viewing Angle : 120°
Dimensions (L x W x D)(mm) : 162*172*175 mm /257*220*210mm (before / after packing)
Supported Mobile Systems : Android
Network Interface : None
Audio Output : None
Image Sensor : 1/2.7''HD color CMOS
Lens : F=3.35mm(wide)-10.05(tele) F=1.6
Zoom : 3x zoom
Effective pixel : 2.1 mega pixel(16:9)
Horizontal Angle : Near-end 128 dgree,Far-end 37 dgree
Pan movement speed : 350 dgree (80 dgree /S)
Video output pixel : 1080P25/30 720P25/30
Dimension(LXWXH) : 162*172*175 mm /257*220*210mm (before / after packing)
Weight : 1.5kg/2.85kg(before / after packing)
Color : Black
Style : 1080p HD PTZ IP Camera with 3x Zoom
Technology : Pan / Tilt / Zoom
Tenveo NV3U USB PTZ Camera 1080P Conference Camera 3x Zoom USB Plug-N-Play for PC laptop Smart TV for Handdle Rooms Conference
USB2.0
HD1080P 2.1 mega pixel
3x optical zoom
Wide angle 90°, Pan: 350°
RS-232, RS-422, RS-485,
IR remote control
Tips: Press the Number(1-9) directly to call the reserved preset. Fast and Smooth
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
Highlisht
-
3x optical zoom
-
Sleek and intelligent design
-
Plug & Play USB Connectivity
-
Crystal clear HD1080P image quality
-
Accurate, smooth and silent PTZ Movement
-
Preset: 9 via IR remote setting (255 via RS232)
-
Superior quality with Full Glass Lens Material
-
128° wide field of view with no video distortion
-
1/2.7 inch high quality, 2.1MEGA PIXEL (16:9) CMOS sensor
-
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
-
2D and 3D NR for best video quality in different lighting conditions
-
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
-
Compatible with most leading video conferencing software and platform
Pictures
Specification
| Product No. |
TEVO-NV3U |
| Image Sensor |
1/2.7 inch HD Color CMOS |
| Effective pixel |
2.1 mega pixel(16:9) |
| Horizontal Resolution |
1080P30/25, 720P30/25 |
| Signal standard |
NTSC/PAL |
| Zoom |
3x optical zoom |
| Focal length |
F=3.35mm(wide)-10.05(tele) F=1.6 |
| Horizontal Angle |
Near-end 128°～Far-end 37° |
| Gain control |
Auto/manual |
| Focus |
Auto/manual |
| SNR ratio |
≥50dB |
| Shutter speed |
8 to 1/10000s (auto) |
| Preset position |
IR remote control supports 9 presets |
| Pan/Tilt movement range |
Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S) |
| Control terminal |
RS-232, RS485 |
| Control Protocol |
VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
| Video output |
USB |
| Video Compression Format |
YUV, MJPEG, H.264 |
| Noise Reduction |
2D/3D |
| Work temperature |
-10°C-~50°C |
| Storage temperature |
-20°C~60°C |
| Baud rate |
38400/9600bps |
| Decoder |
Built-in |
| Address set |
1~64 |
| Installation |
Support desktop, Tripod, Wall mount and Ceiling mount |
| Power supply |
DC12V/ 2A |
| Power consumption |
12 W |
| Net weight/Gross weight |
1.5kg/2.85g |
| Dimension(LXWXH) |
162*172*175 mm /257*220*210mm (before / after packing) |
| Accessories |
DC 12V Power adaptor, IR remote control, Manual, USB2.0 cable, Ceiling brackets & screws. |
What's in the box
1 X Camera
1 X DC 12V power adaptor
1 X IR remote control
1 X Manual
1 X USB2.0 cable
1 X Brackets & screws
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms, and large auditorium spaces.You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants, which could be 500 people dialing in from their laptops, pad or mobile phones, 500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, Easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
