Excellent non-line-of-sight transmission performance
It extends the application wireless video transmission to more complex scenarios, such as video transmission between different floors, indoor to outdoor transmission, outdoor blocking scenario, etc(Other brands of ordinary wireless transmissions are blocked by obstacles and cannot be used.)
Base on advanced wireless transmission technology, Thunder has Excellent non-line-of-sight transmission, anti-interference, and ultra-long-distance transmission performance. It extends the application wireless video transmission to more complex scenarios, such as video transmission between different floors, indoor to outdoor transmission, outdoor blocking scenario, etc
Product features
1. Excellent non-line-of-sight transmission performance.
2. Ultra-long distance range up to 1KM (LOS).
3. Ultra-low video transmission latency to 70ms.
4. Up to 1080p60.
5. Support SDI & HDMI input, dual SDI output and SDI loop out.
6. Support audio Line-in and Line-out.
7. Support Tally, RS232/422/485 control signals.
| Transmitter*1 | Receiver*1 | |
| Antenna Mode | 1T1R+1R | |
| Transmission delay | 70ms | |
| Operating frequency | 1.4GHz | |
| Transmission power | 33dBm +/- 1dBm | / |
| Interface | Output：Tally, RS232/422；Input: HDMI, SDI | Output：HDMI, SDI, SDI环出；Input: Tally（DB9), RS232/422 |
| resolving power | 720p50/59.94/60，1080p23.98/24/25/29.97/30/50/59.94/60，1080i50/59.94/60 | |
| Power consumption | 12W | |
| Operating voltage | 7~36V | |
| Transmission Distance | 1.2km (20MHz, 15Mbps) | |
| Receiving Sensitivity | / | -94dbm@4Mbps |
| Temperature | 0~40 C(Working);-20~80 C(Storage) | |
| Bandwidth | 5MHz， 10MHz ，15MHZ，20MHZ | |
| Audio Format | PCM,MP2 | |
| Working power supply | DC12V / 2A | |
| SDI protocol | HD/3G(A/B) ；SMPTE 296M ；SMPTE 274M | |
| Network mode | Peer to peer private protocol, RTSP protocol | |
| Product Size | 155*94*35mm ( MAX:157*102*44 mm） |
Excellent non-line-of-sight transmission performance
It extends the application wireless video transmission to more complex scenarios, such as video transmission between different floors, indoor to outdoor transmission, outdoor blocking scenario, etc
A wonderful experience for multi-scenario applications
Excellent non-line-of-sight transmission, anti-interference, and ultra-long-distance transmission performance, widely adaptable to all types of cameras and monitors. It can adapt to multi-scene applications, such as weddings, concerts, sporting events, education, churches, etc.
