RM-7029S _ Dual 7 inch 3RU rackmount monitor with 3G-SDI /HDMI 2.0
Short Description:3RU rack mount monitor with dual 7″ IPS screens, which is suitable for monitoring from two different cameras simultaneously.It comes with SDI and HDMI input and output, which support up to 1080p 60Hz SDI and 2160p 60Hz HDMI videos. Just add signal cables to expand more diverse display solutions through loop output interfaces. Help creating a camera video wall. Also all monitors can be perfectly adjusted by a connected computer under the control of software.So you can focus on other operation on the workbench at the same time.
Model No.:RM-7029SDisplay:Dual 7″ ,1920x1200Input:3G-SDI, HDMI 2.0, LANOutput:3G-SDI, HDMI 2.0Feature:Rack mount, Easy Remote Control
Display | |
Size | Dual 7″ LED backlit |
Resolution | 1920×1200 |
Brightness | 400cd/m² |
Aspect ratio | 16:10 |
Contrast | 2000:1 |
Viewing Angle | 160°/160°(H/V) |
HDR | ST 2084 300/1000/10000 / HLG |
Supported Log Formats | Slog2 / Slog3, Arrilog, Clog, Jlog, Vlog, Nlog or User… |
LUT Support | 3D-LUT (.cube format) |
Video Input | |
SDI | 2×3G |
HDMI | 2×HDMI(supports up to 4K 60Hz) |
LAN | 1 |
Video Loop Output | |
SDI | 2×3G-SDI |
HDMI | 2×HDMI 2.0 (supports up to 4K 60Hz) |
Supported In / Out Formats | |
SDI | 1080p 60/50/30/25/24, 1080pSF 30/25/24, 1080i 60/50, 720p 60/50… |
HDMI | 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50, 720p 60/50… |
Audio In/Out | |
Speaker | - |
Ear Phone Slot | 2 |
Power | |
Current | 1.5A |
DC In | DC 10-24V |
Power Consumption | ≤16W |
Environment | |
Operating Temperature | 0℃~50℃ |
Storage Temperature | -20℃~70℃ |
Other | |
Dimension(LWD) | 480×131.6×29.3mm |
Weight | 2.2kg |
