Key Features
Maintains Focus Throughout Zoom Range
Near-Zero Breathing
Swappable PL Mount; Canon EF Included
16-Blade Iris
Focus, Iris, and Zoom Lens Ring Gears
95mm Front Diameter
DZOFilm Pictor 20-55mm T2.8 Specs
Focal Length | 20 to 55mm |
Lens Mount | ARRI PL |
Lens Format Coverage | Super35/APS-C |
Image Circle | 31.1 mm |
Maximum Aperture | T2.8 |
Minimum Aperture | T22 |
Diaphragm Blades | 16 |
Gear MOD & Pitch | Focus: 0.8 MOD / 32 Pitch |
Front Diameter | 95 mm |
Filter Thread | 86 mm |
Focus Scales | Imperial |
Zoom Ratio | 2.75x |
Electronic Communication | No |
Image Stabilization | No |
Lens Support | Lens Support Foot |
Length | 6.46'' / 164 mm |
Weight | 3.35 lb / 1.52 kg |
Package Weight | 6.015 lb |
Box Dimensions (LxWxH) | 13.1 x 7 x 7'' |
