SPARK 400D Studio Flash
0.9S Recycling Time at 400Ws Full Power
13500Lux /,LED Modeling lamp /
LCD Display Screen 6 F-Step
Continuous Shooting
Restore Details Easy Cap
Built in Wireless Remote

Parameters

F-stop range: 4.0-9.0 (1/1-1/32)

Recycling time: 0.1-0.9s

SYNC Mode: Nor mode(Nikon<1/320s, Canon/Sony/Fuji < 1/250s

Flash Duration(t=0.5): 1/800s-1/2200s

Modeling Lamp (W): 15W LED (≥ 150W Halogen lamp)

Color temperature: 5500k±200k

2.4GHz wireless control

16 groups, 32 channels

Net Weight: Approx. 3.08lbs

Operating Voltage: AC 110V

Support Buzz/Cell/Easycap

Size: 265x132x215mm

Power Output

Turn directly to set strobe power output displays from Min 4.0~Max 9.0

Buzz

Long press Button''Modeling lamp/Buzz button''to turn on Buzz. A beep will be delivered indicating recycling is done after flash. Turning on Buzz will shut down Recycling Indication Function of Modeling Lamp automatically.

Modeling Lamp Function

1. Short press Button''Modeling lamp/Buzz button''to switch modes of modeling lamp: Proportion/l00% Full/Off

2. Proportion Mode: Brightness will be proportional to flash power output. Max at 9.0, Min at 4.0

3. 100% Full: Stays at Max brightness

4. Recycling Indication: It will be automatically activated when modeling lamp is turned on(Buzz off). Modeling Lamp will be off when the strobe flash and it will be on again when recycling is completed. When Buzz is on, this function will be disactivated and modeling lamp will be constantly on.

Easycap

Long press Knob''Multi-function knob''to turn on Easycap. Turn and short press Knob''Multi-function knob'',Number 1 for firing at first trigger, Number 2 for firing at 2nd trigger.

Wireless

Short press Button''wireless setting button'', Turn Knob''multi-function knob''to set wireless mode, and short press again to confirm. Long press Button''wireless setting button''to turn off wireless.

Wireless Mode & Matching Transmitters

TR-V6--'6' / TR-Q7--'7' / TRS-V--'0' / TR-Q6--'C'/'N'/'S'/'F'

CH Setting

Short press Knob''multi-function knob'', Turn Knob ''multi-function knob''to choose CH value. It will be confirmed automatically without operation in 2 seconds. CH Value ranges 00~31.

GR Setting

Short press Knob''multi-function knob''again, Turn Knob''multi-function knob''to choose GR value. It will be confirmed automatically without operation in 2 seconds. GR Value ranges ''A/B/C/D/E/F/G/H/l/J/L/O/P/Q/S/U''.
