Brand Name : TENVEO
Certification : CE
Certification : FCC
Certification : RoHS
Max. Resolution : 1920x1080
Origin : CN(Origin)
Model Number : NV20A
Auto Focus : Yes
Package : Yes
Interface Type : USB
Pixels : 2 Mega
Image Sensor : CMOS
Image Sensor : 1/3 inch type Exmor CMOS
Lens : F=5.5mm(wide)-110(tele)
Zoom : 20x zoom
Effective pixel : 2.38 mega pixel(6:9)
Pan movement speed : 350 dgree (100 dgree/S)
Minimum illumination : 0.25Lx(on)
Color : Black
Style : SDI Camera
Technology : Pan/Tilt/Zoom
Near-end 54.7°-Far-end 3.3° : Near-end 54.7°-Far-end 3.3°
Tenveo NV20A USB HDMI SDI Conference Camera HD 1080p PTZ Indoor Camera SDI Camera 20X Zoom Cam Action Video Conference Webcam
USB, 3G-SDI, HDMI
HD1080P
2.38 mega pixel
20X optical zoom
Pan: 350° Tilt : 90°
VISCA, PELCO-D/P, RS232, RS485
Tips1. : Press the Number(1-9) directly to call the reserved preset. Fast and Smooth
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
Tip2: SDI support 328ft(100m) video transfer, HDMI support 98ft(30m) HD video transfer and USB support 66ft(20m) HD video transfer.
Tip 3: Image Flip and Image Mirror. Press MENU - IMAGE - Mirror, and adjust Left/Right/UP/DOWN to manipulate image flip and Mirror.
Highlight
20x optical zoom
Sleek and intelligent design
Plug & Play USB Connectivity
Accurate, smooth and silent PTZ Movement
Preset: 9 via IR remote setting (255 via RS232)
Wide field of view with no video distortion
1/3 inch high quality, 2.1MP (16:9) CMOS sensor
Superior quality with Full Glass Lens Material
Support HD1080P60/50/30/25,720P60/50,etc.
Support USB, HDMI and SDI 3 video output at the same time
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
2D and 3D NR for best video quality in different lighting conditions
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
Compatible with most leading video conferencing software and platform
Pictures
Specification
Model No. | TEVO-NV20A |
Image Sensor | 1/3'' CMOS |
Effective pixel | 2.38 mega pixel(16:9) |
Horizontal Resolution | 1080P60/50/30/25, 1080i60/50, 720P60/50 |
Focal length | F=5.5mm(wide)-110(tele) |
Signal standard | NTSC/PAL |
Zoom | 20x zoom |
Horizontal view angle | Near-end 54.7°～Far-end 3.3° |
Gain control | Auto/manual |
Focus | Auto/manual |
SN ratio | ≥50dB |
Shutter speed | 1/30 sec to 1/10,000s, auto |
Preset position | Remote-controller support 9 presets PELCO Control Protocol supports 255 presets |
Pan/Tilt movement range | Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S) |
Control terminal | RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
Video output | USB, SDI, HDMI |
Noise Reduction | 2D/3D |
Work Temperature | -10°～50° |
Work Humidity | -20°～60° |
Baud rate | 34800/9600bps |
Decoder | Built-in |
Address Set | 1~64 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply | DC12V/2A |
Power | 12W |
Weight | 1.5kg/2.85kg(before / after packing) |
Size | 162*172*175mm /257*220*210mm (before / after packing) |
Accessories | DC 12V Power adaptor, IR remote control, Ceiling brackets & screws, Manua |
What is in the box
1 X Camera
1 X USB Cable
1 X DC 12V power adaptor
1 X IR remote control
1 X Celling Brackets
1 X Manual
Tenveo Camera FAQ
Q:What kind of camera should I use?
A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software.For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces.You can check our service guide for more information on different meeting room systems.
Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.
Q:Can I bring more than one person into a call at the same time?
A:Yes. We currently offer group calling for up to 500 different participants,which could be 500 people dialing in from their laptops ,pad or mobile phones,500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.
Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.
Q:What is the Video Connector?
A:There are USB 2.0, USB3.0,HDMI,HD-SDI,DVI,YPBPR and CVBS Video output.
Q:How many time zoom?
A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.
Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.
Q:Which kind of software compatible with this Camera?
A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh,WebEx, easy meeting, Vidtel and working with Microsoft Lync Software,and ZOOM.US, SKYPE, VIDYO Etc.
