Brand Name : TENVEO



Origin : CN(Origin)



Type : Video Conference System



Simultaneous Interpretation : No



Function : video conference



Model Number : TEVO-NV20U



Sensor : 1/3'' type Exmor CMOS



Effective pixel : 2.1 mega pixel



Preset position : 255



Gain control : Auto,manual



Wide dynamic : D-WDR



Video output : USB2.0



Control terminal : RS232 RS485 RS422



Video output pixel : 1080P 720P



Signal standard : NTSC PAL



Lens : 20x optical zoom



Support : YUV, MJPG, H.264

















Tenveo NV20U 2MP 20x Zoom USB PTZ Video Conference Camera HD 1080p USB Plug and Play Camera Pan Tilt Zoom For Teleconference








USB2.0 video output


1/3'' Exmor CMOS


2.1 mega pixel


HD1080P


20X optical zoom


Pan: 350° Tilt :90


°


Support RS-232, RS-485,


With IR remote control




Tips: Press the Number(1-9) directly to call the reserved preset. Fast and Smooth



PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.




















Highight

•





• 20x optical zoom



•





• Sleek and intelligent design



•





• Plug & Play USB2.0 Connectivity



•





• Crystal clear HD1080P image quality



•





• Preset: 9 via IR remote setting (255 via RS232)



•





• Wide field of view with no video distortion



•





• 1/3 inch high quality, 2.1MP (16:9) CMOS sensor



•





• Superior quality with Full Glass Lens Material



•





• Support ceiling mount, wall mount and tripod mount (Reverse mountable)



•





• 2D and 3D NR for best video quality in different lighting conditions



•





• Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control



•





• Compatible with most leading video conferencing software and platform



•





• Utilizing belt drive technology the PTZ is ultra-quiet and fast, while being very smooth



•









•
•








Pictures






























Specification






















































































































































































































































































































































































Product No.	TEVO-NV20U
Image Sensor	1/3 inch Exmor CMOS
Effective pixel	2.1 mega pixel（16:9）
Horizontal Resolution	1080p30/25, 720p30/25
Signal standard	NTSC/PAL
Zoom	20x optical zoom
Focal length	F=5.0mm(wide)-50.0(tele) F=1.8(W)-2.1(T)
Horizontal Angle	Near-end 55.5°～Far-end 3.0°
Gain control	Auto/manual
Focus	Auto/manual
SNR ratio	≥50dB
Wide dynamic	D-WDR
Shutter speed	8to1/ 10000s(auto)
Preset position	IR remote control supports 9 presets PELCO Protocol supports 255 presets
Pan/Tilt movement range	Pan: 350°(max speed 100°/S), Tilt: 90°(max speed 80°/S)
Control terminal	RS-232, RS485
Control Protocol	VISCA, PELCO-D, PELCO-P（RS-232, RS485）
Video output	USB
Noise Reduction	2D/3D
Work temperature	-10°C-~50°C
Storage temperature	-20°C~60°C
Baud rate	2400/4800/9600/19200bps
Decoder	Built-in
Address set	1~64
Installation	Support desktop, Tripod, Wall mount and Ceiling mount
Power supply	DC12 V/ 2A
Power consumption	12 W
Net weight/Gross weight	1.5kg/2.85kg(before / after packing)
Dimension(LXWXH)	162*172*175mm /257*220*210mm (before / after packing)
Accessories	DC 12V Power adaptor, IR remote control, Manual, USB 2.0 cable, Ceiling brackets & screws.




What's in the box






1 x Camera


1 x DC/12V power adaptor


1 x IR remote control


1 x Manual


1 x USB cable


1 x Brackets & screws


1 x Warranty


1 xCertificate of qualification






Tenveo Camera FAQ



Q:What kind of camera should I use?



A:Most laptops and monitors come with built-in cameras—these work great for Tenveo software. For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces. You can check our service guide for more information on different meeting room systems.





Q:Is it easy to operation?



A:Yes, it is easy to install, plug and play.





Q:Can I bring more than one person into a call at the same time?



A:Yes. We currently offer group calling for up to 500 different participants, which could be 500 people dialing in from their laptops, pad or mobile phones, 500 different video conferencing systems full of people or some mix of individuals and video conferencing systems.





Q:What is the resolution of your cameras?



A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.





Q:What is the Video Connector?



A:There are USB 2.0, USB3.0, HDMI, HD-SDI, DVI, YPBPR and CVBS Video output.





Q:How many time zoom?



A:Support fixed focus, 3X, 10X, 20X, 30X optical zoom.





Q:How to control this Camera?



A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-P, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.





Q:Which kind of software compatible with this Camera?



A:It's compatible with PolyCom, Blue Jeans, Cisco, Vsee, GoToMeeting, Radvision, SeeVogh, WebEx, Easy meeting, Vidtel and working with Microsoft Lync Software, and ZOOM.US, SKYPE, VIDYO Etc.
