JINBEI Photography Light Studio SPARK 400D 400W Strobe Flash Lights GN66 Photo Monolight Speedlite for Indoor Portrait Photography

Used for cloth, shoes, make up, daily products, electronic products etc. shooting, compact and portable, easy to carry.

Specification:

• Model: SPARK-400D

• Type: Studio Flash

• Max Power/GN: 400Ws/GN66

• Recycle Time: 0.1s-0.9s

• SYNC Mode: Nor mode(Canon/Sony/Fuji<1/250s, Nikon:1/320s)

• Flash Duration(t=0.5): 1/800s-1/2200s

• Color Temperature/CCT: 5500°K ± 200°K

• Modeling Lamp: 15W LED

• Flash Power Variation: 6F-stop 1/1-1/32 output variation

• 2.4GHz Wireless System: Compatible with TR-A3/A9; TRS-V; TR-V6;

• Range: >100m

• Cell/Beep/Easycap:Support

• Operating: AC 195~245V 50/60Hz

• Dimension: 265(L)x132(W)x215(H)mm

• Weight: 2.5 kg

Features:

1. Recycle Time 0.9s(Full power)

2. Excellent Cooling System with overheating protection. Durable, Continuous flash shooting

3. Standard color temperature, 5500°K ± 200°K, picture is more vivid

4. 6 gear dimming range, output accuracy 1%

5. 15w modeling lamp with adjustable brightness

6. Built-in easycap function to improve efficiency

7. Built-in JINBEI 2.4GHz wireless system, wireless remote control

8. LCD multi-function display,

9. Quickly installs various JINBEI mount light accessories such as DM90 softbox

Standard List Include: SPARK 400D Light Body*1 + Plastic Protector*1 + Power Cable *1

Reflector Kit Include: Standard List + 55 Degrees Standard Reflector*1

Trigger Kit Include: Standard List + TR-V6 Transmitter*1

Power Output

Turn directly to set strobe power output displays from Min 4.0~Max 9.0

Buzz

Long press Button"Modeling lamp/Buzz button"to turn on Buzz. A beep will be delivered indicating recycling is done after flash. Turning on Buzz will shut down Recycling Indication Function of Modeling Lamp automatically.

Modeling Lamp Function

1. Short press Button"Modeling lamp/Buzz button"to switch modes of modeling lamp: Proportion/l00% Full/Off

2. Proportion Mode: Brightness will be proportional to flash power output. Max at 9.0, Min at 4.0

3. 100% Full: Stays at Max brightness

4. Recycling Indication: It will be automatically activated when modeling lamp is turned on(Buzz off). Modeling Lamp will be off when the strobe flash and it will be on again when recycling is completed. When Buzz is on, this function will be disactivated and modeling lamp will be constantly on.

Easycap

Long press Knob"Multi-function knob"to turn on Easycap. Turn and short press Knob"Multi-function knob",Number 1 for firing at first trigger, Number 2 for firing at 2nd trigger.

Wireless

Short press Button"wireless setting button", Turn Knob"multi-function knob"to set wireless mode, and short press again to confirm. Long press Button"wireless setting button"to turn off wireless.

Wireless Mode & Matching Transmitters

TR-V6--'6'   /   TR-Q7--'7'   /   TRS-V--'0'   /   TR-Q6--'C'/'N'/'S'/'F'

CH Setting

Short press Knob"multi-function knob", Turn Knob "multi-function knob"to choose CH value. It will be confirmed automatically without operation in 2 seconds. CH Value ranges 00~31.

GR Setting

Short press Knob"multi-function knob"again, Turn Knob"multi-function knob"to choose GR value. It will be confirmed automatically without operation in 2 seconds. GR Value ranges "A/B/C/D/E/F/G/H/l/J/L/O/P/Q/S/U".
